🏛️ Uberblok: An Interactive Gallery of ZFS Internals

Uberblok serves as a digital museum dedicated to the inner workings of ZFS, allowing users to explore the filesystem by reading its actual source code.

Storage systems have historically fought a constant war against ~~unreliable hardware~~:

Disks that report false data (silent corruption).
Writes that are interrupted mid-stream.
System crashes occurring during critical updates.

This interactive experience guides you through these challenges, one "room" at a time, mapping animations directly to the OpenZFS source (specifically version zfs-2.4.4, frozen at commit 71a9f9578616).

🖼️ The Hall: The Uberblock

The centerpiece of the museum is the struct uberblock, found in include/sys/uberblock_impl.h (lines 122–128).

struct uberblock {
    uint64_t ub_magic;    // Magic number: 0x00bab10c
    uint64_t ub_txg;      // Transaction group of the last sync
    blkptr_t ub_rootbp;   // Block pointer to the MOS (root of the tree)
    // ... other fields ...
};

The Purpose of the Uberblock

A ZFS pool consists of millions of blocks scattered across multiple disks. To avoid scanning every single block after a crash, ZFS uses a single, small record to identify the current consistent state: the uberblock.

It contains two vital pieces of information:

ub_txg: The transaction group number.
ub_rootbp: The pointer to the MOS (Meta Object Set), from which every other block in the pool can be reached.

The Ring Architecture

To ensure safety, ZFS doesn't overwrite the current uberblock. Instead, it uses a ring buffer system:

Placement: Each disk has four labels (two at the start, two at the end).
Storage: Each label contains a 128 KiB ring of uberblocks.
Rotation: A new uberblock for transaction group $N$ is placed in a slot determined by: $\text{slot} = N \pmod{\text{total slots}}$ (Note: If multihost=on, one slot is reserved for MMP, reducing the available ring size by one).

Import Process: Upon importing a pool, ZFS scans every slot on every label and selects the valid uberblock with the highest ub_txg.

Capacity and Sectoring

The total space is 128 KiB. The number of available slots depends on the disk's sector size (ashift):

Sector Size (ashift)	Slot Size	Total Slots
512B (ashift 9)	1 KiB	128
1 KiB (ashift 10)	1 KiB	128
2 KiB (ashift 11)	2 KiB	64
4 KiB (ashift 12)	4 KiB	32
8 KiB+ (ashift 13+)	8 KiB	16

Interactive Tip: In the museum, you can adjust the sector size to see how subsequent txgs occupy different slots. You can also zoom ( $\pm$ ) and rotate the 3D view.

🗺️ Map of the Visit

The museum is organized to follow the flow of data, from the root of the tree to the underlying hardware.

📜 A Legacy of Engineering

ZFS was built on a fundamental distrust of hardware. As Bill Moore put it:

"Never, ever trust the underlying hardware."

This museum is a tribute to the pioneers of this architecture:

Jeff Bonwick: Lead developer.
Bill Moore: Co-lead.
Matt Ahrens: One of the two original authors.

The project began at Sun Microsystems in 2001. By the time it integrated into Solaris on October 31, 2005, the effort had spanned:

5 years of development.
56 patents.
92,000 lines of changes across 584 files.

Bonwick reflected on the magnitude of the achievement:

"I’m incredibly proud of the ZFS team, and deeply grateful: no one person can do something on this scale."

The museum also honors Sun's culture of transparency and academic contribution, citing milestones like the Slab Allocator (1994) and DTrace (2004), and the eventual release of ZFS under the CDDL. Today, this legacy is carried forward by OpenZFS (est. 2013), a community effort involving Linux, FreeBSD, macOS, and illumos, with over 700 contributors listed in its AUTHORS file.

🛠️ The Physical Layer

To ground the software in reality, the museum references the physical 3.5-inch hard drive:

Top cover & Base casting
Disc clamp & Platters
Head stack (Arms and heads)
Voice coil (and magnet)
Spindle motor
